Volvo B19-B230 8V injection Plenum / Intake for 80mm damper

Volvo B19-B230 8V aluminum intake kit for injection engine Volvo 240, 740 and 940 NOTE! the stud bolts and nuts of the flange between the intake manifold and the intake housing must be tightened when assembling, the sealing is done with a large O-ring. Used for manufacturing with CNC machines, so that the compatibility and flatness of the connection surfaces is top notch If you wish, you can disassemble the intake manifold by loosening the nuts, e.g. for reconciliation The throttle unit is a separately purchased and installed unit that also enables the use of other throttle manufacturers. Channel size: The diameter of the suction channel is approx. 50 mm on the side of the suction housing and it tapers like a cone all the way around 30 mm before the cover connection at the point where the spray nozzles are attached, it tapers to 40 mm, which is also the diameter of the cover mounting flange hole. There is also an opportunity to polish and grind the intake duct, because it has a few, e.g. material strength allows it. The total length of the suction channel is approx. 175mm The intake manifold goes to e.g. this 80mm throttle unit, which is sold separately in the online store. The intake manifold goes to e.g. this 8/16V fuel rail, which is sold separately in the online store.
