AE86 4age Link FuryX G4 Kit
$59.49
$72.58
Description MRP Link FuryX with Full Engine Loom Harness If you like the value of the MonsoonX, but are looking for a couple of extra features, then the StormX is the ECU for you. Especially if you are planning on running a turbo setup with lots of external controllers This allows you to plug the ECU directly into your car with a few additional wires to wire in Contents: – FuryX – MRP AE86 Full Engine Loom – Motorsport Grade – Start up Map – We can setup for Coil on Plug or stock lead setup – 16v & 20v Available The FuryX has more inputs (digital, analogue and temp), as well as Traction Control SPEC OVERVIEW: Inputs 8/10* x Digital inputs 4 x Temperature inputs 9 x Analog inputs 2 x Trigger inputs 2 x Knock inputs 1 x LSU 4.9 Wideband lambda sensor input Outputs 8 x Injection drives 6 x Ignition drivers 10 x Auxiliary outputs^ 5V Sensor power supply 8V Sensor power supply ^unused fuel and ignition drives can be used as additional Aux outputs Communications 2* x CAN bus 1x Serial (RS232) connection 1x USB tuning connection Physical Dimensions: 185mm(L) x 130mm(W) x 40mm(H) (without looms) Mass: 680grams *DI 9 & 10 pins used by second CAN Bus What’s in the box? Supplied with USB tuning cable and mounting bracket.
Ecu Link
